UFO Led High Bay lights are using high luminous efficiency led source, providing excellent lumen output, Long-lasting stability and splendid sight.
SYH LED High Bay lights are using high-end LED driver withlong lifespan. Provide 5 years warranty on luminaire.
|
Power |
W |
50W |
80W |
100W |
120W |
150W |
200W |
240W |
|
Heat sink |
mm |
Φ230/Φ270/Φ315/Φ350 |
||||||
|
Input Voltage |
V |
AC100-277V/AC347V/AC200-480V |
||||||
|
Color Temperature |
CCT |
2700K-6500K |
||||||
|
Luminous efficiency |
lm/w |
180lm/w,200lm/w |
||||||
|
CRI |
|
>80 |
||||||
|
Frequency |
Hz |
50Hz-60Hz |
||||||
|
Power Factor |
PF |
>0.95 |
||||||
|
Rating |
/ |
IP65 |
||||||
|
Beam Angle |
℃ |
60°/90°/120°/160° |
||||||
|
Working Temperature |
℃ |
-35℃~+65℃ |
||||||
|
Life span |
/ |
L70B50,>100,000Hours |
||||||
|
Warranty |
|
>5 years |
||||||
|
Certificate |
|
DLC UL cUL CE ROHS |
||||||
|
Control protocol(s) |
|
0-10V,DALI2,MicroWave Sensor,IR Sensor |
||||||
|
Material |
/ |
Die Casting Aluminium Housing |
||||||
|
Gross Weight |
Kgs |
2.0Kgs,2.5Kgs,3.5Kgs |
||||||
